Product Specification

AC Input AC100-240V 50-60Hz
DC Output +5V +3.3V +12V -12V +5VSB
Max. Output Current 15A 15A 49A 0.5A 2.5A
Max. Combined Wattage 1000W 588W 18.5W

-AC I/P Voltage Range : 230Vac With Active Pfc

-DC O/P Voltage : +12V, +5V, +3.3V, -12V, +5VBS

-Always-on Standby Voltage : +5VSB/3A

-Operating Temperature Range From 0C To 40C

-Apfc + Double Forward + Magnetic Amplification

-Compatible Desktop Power Supply Design Guide Revision 2.31

-Pass 80plus Bronze (82% 85% 82%)

-Fit In With Erp Lot 3 2013

-120mm Variable Fan Speed Control To Keep Low Noise

-Protection : OVP / UVP / ASCP / OPP

-Longer Flat Cable Markes Cable Management Perfectly

-Ready For Intel & Amd Cpu Support Pci-e Vga Card(s)

-CONDUCTED EMI : MEET FCCPART 15 CLASS B ; BEN55032 2015 : BSMI : CNS 13438, CNS 14336

-Safety standards : MEET CUL/UL(UL 62368-1); TUV (EN62368-1); CB (IEC 62368-1); CE(EN55035) HARMONIC IEC1000-3-2,Class D
